Specifications
On this page you find the Fisher & Paykel RF540ADUSX4 manual. Please read the instructions in this operator manual carefully before using the product. If you have any questions about your that are not answered in the manual, please share your question in the. Shop Online for Fisher & Paykel RF610ADX5 Fisher & Paykel 614L French Door Refrigerator and more at The Good Guys. Grab a bargain from Australia's leading home appliance store.
Configuration| Adjustable glass shelves |
| Adjustable roller feet |
| Covered door shelves | 2 |
| Egg trays | 2 |
| Four shelves (incl above vegetable area) |
| Freezer door pockets | 3 |
| Freezer shelves | 1 |
| Front levelling feet |
| Fruit and vegetable bin divider |
| Ice cube trays | 2 |
| Rear rollers |
Fisher Paykel Dishwasher Manual
Consumption Data| Energy Star rating | 2.5 |
| Energy usage (kWh/yr) | 484 |
Design| Door opening | Available left and right |
| Elegant flat, curved, metal handle |
| Interchangeable doors (conversion kit required) |
| Top mount freezer |
| White prepaint cabinet |
Dimensions| Height - incl. feet and hinge cap | 1695mm |
| Width | 790mm |
| Depth - including handle | 730mm |
| Depth door open 90 ° | 1408mm |
| Depth - door closed not including handle | 715mm |
| Minimum air clearance - each side | 20mm |
| Minimum air clearance - at rear (incl. compressor tray) | 30mm |
| Minimum air clearance - on top | 50mm |
| Refrigerator gross volume | 400 litres |
| Freezer gross volume | 117 litres |
| Total gross volume | 517 litres |
| Total net volume | 479 litres |
Performance Features
| ActiveSmartâ„¢ system |
| Adaptive defrost |
| Door alarm - freezer |
| Door alarm - refrigerator |
| Frost free |
| Humidity Control System |
| Humidity controlled fruit and vegetable bins | 1 |
| LED lighting |
| R600a refrigerant |
Warranty
| 2 year parts & labour warranty, plus additional 3 year sealed system parts warranty |
Fisher And Paykel Fridge Manual Activesmart
Installation ManualsTo view and print these PDF documents, you will need Adobe Acrobat Reader
- Integration Kit Instructions - Series B, C, D & G English
- Refrigeration Installation InstructionsEnglish
User Guides
To view and print these PDF documents, you will need Adobe Acrobat Reader
- 7257_NZ_AU_Refrigerator and Freezer_HREnglish
Check with your local retailer for pricing, availability and stock of this model. The product dimensions and specifications in this page apply to the specific product and model. Under our policy of continuous improvement, these dimensions and specifications may change at any time. You should therefore check with your retailer or Fisher & Paykel's Customer Care Centre to ensure this page correctly describes the model currently available.
Specifications
Configuration| Adjustable glass shelves |
| Adjustable roller feet |
| Clear freezer bins | 3 |
| Covered door shelves | 2 |
| Deli storage area |
| Front levelling feet |
| Full extension runners |
| Full width door shelves | 2 |
| Gallon bottle storage shelves |
| Half width adjustable door shelves | 4 |
| Ice bin and scoop |
| Rear rollers |
| Single bottle holders | 4 |
| Three shelves (incl above vegetable area) |
| Full extension freezer drawer |
Consumption Data| Energy Star rating | 3.5 |
| Energy usage (kWh/yr) | 453 |
Design| Concealed hinges |
| EZKleen stainless steel |
| Flat door design |
| French Door refrigerator |
Dimensions| Depth - door closed not including handle | 695mm |
| Depth - including handle | 730mm |
| Height - incl. feet and hinge cap | 1790mm |
| Minimum air clearance - at rear (incl. compressor tray) | 30mm |
| Minimum air clearance - each side | 20mm |
| Minimum air clearance - on top | 50mm |
| Width | 900mm |
| Refrigerator gross volume | 433 litres |
| Freezer gross volume | 181 litres |
| Total gross volume | 614 litres |
| Total net volume | 568 litres |
Performance Features| ActiveSmartâ„¢ system |
| Adaptive defrost |
| Bottle chill |
| Built in ice maker |
| Door alarm - freezer |
| Door alarm - refrigerator |
| Fast freeze |
| Frost free |
| Humidity Control System |
| Humidity controlled fruit and vegetable bins | 2 |
| Ice Boost |
| LED lighting |
| R600a refrigerant |
| Smart Touch control panel |
| Soft close doors |
| Ultraslim water dispenser |
Warranty| 2 year parts & labour warranty, plus additional 3 year sealed system parts warranty |
Installation ManualsFisher & Paykel User Manual
To view and print these PDF documents, you will need Adobe Acrobat Reader
- Global U2 Installation InstructionsEnglish
- Surround Kit Installation InstructionsEnglish
Fisher Paykel Service Manual
User GuidesTo view and print these PDF documents, you will need Adobe Acrobat Reader
- ActiveSmart Refrigerator Use & Care 2015English
Check with your local retailer for pricing, availability and stock of this model. The product dimensions and specifications in this page apply to the specific product and model. Under our policy of continuous improvement, these dimensions and specifications may change at any time. You should therefore check with your retailer or Fisher & Paykel's Customer Care Centre to ensure this page correctly describes the model currently available.
