For customers who need an advanced Holter monitoring solution, the Burdick ® Vision Premier Holter system provided an affordable and powerful diagnostic tool. The Vision Premier system adds expanded viewing choices and a more comprehensive list of diagnostic tools to the easy-to-use Vision software.
DESCRIPTION
Burdick Vision 5L & 5LR Digital Holter RecorderBurdick 4250 Troubleshooting
The Burdick Vision 5L and Burdick 5LR Digital Holter Recorders provide high-quality 5- or 7-lead, 3-channel Holter recordings with an ECG signal preview screen. Fast data transfer using a compact flash card frees the recorder for immediate assignment to the next patient.
FORUMSView All (6)
Ask a New QuestionBurdick 4250 Holter Recorder Manual
Burdick Holter Monitor Software
2Replies10 days ago | 10 days agoLeads Would reading be effected if brown lead is put where black lead is supposed to be? Thank you Reply |
| -Dr Spok 9 months ago | 9 months agoRepair Does anyone out there repair these recorders ?Reply |
2Replies3 years ago | 3 years agoNeed leadwire set Where can I purchase a leadwire set for this holter? Reply |
DOCUMENTS / MANUALSView All
FEATURES
Burdick Holter Monitor Instructions
Features
- 5- or 7-lead, 3-channel recordings on a straightforward screen.
- Streamlined five-button keypad.
- “Event button” to let patients capture and mark episodes that concern them.
- Downloadable directly to Vision or Vision Premier analysis software.
- LCD screen to confirm the electrode contacts are properly functioning.
- Patient ECG capture at 200 samples per second over a period up to 48 hours (5L).
- Integrated pacemaker detection.
Benefits
- Real-time ECG display. LCD displays real time ECG hook-up eliminating the need for test jacks and repeat tests.
- Ease of use. Easy-to-use five-button keypad to enter patient and test parameters.
- Convenience. The removable compact flash card lets you send out the Holter recorder right away, without having to wait to download previous patient results.
- Speed. Fast data transfer to Burdick Vision or Burdick Vision Premier Holter analysis software for quick turnaround.
- Versatility. Integrated pacemaker detection lets you use the Holter recorder even on patients with pacemakers.
- Accuracy. An ECG sampling rate of up to 1,000 samples per second (5LR only) captures even the smallest changes.
Additional Specifications
CHANNELS: 3 channels
RESOLUTIONS: For the 5L: 8–bit sampling, 4X oversampling
RECORDING: Full Disclosure Programmable
DOWNLOAD INTERFACE: Removable compact flash (Non-volatile)
SAMPLE RATE: 200 samples per second
FREQUENCY RESPONSE: 0.05Hz to 60Hz @ -3dB
SIGNAL VERIFICATION: LCD Display – ECG Display on LCD
MEMORY
Recording time: User selectable 24 or 48 Hours
Type: Preprogrammed, Burdick non-volatile flash memory
Capacity: 128 MB (Removable)
PHYSICAL
Dimensions: 3.75
SERIES MODELS
| EKG/ECG Type | Holter |
| Additional Specifications | CHANNELS: 3 channels RESOLUTIONS: For the 5L: 8–bit sampling, 4X oversampling RECORDING: Full Disclosure Programmable DOWNLOAD INTERFACE: Removable compact flash (Non-volatile) SAMPLE RATE: 200 samples per second FREQUENCY RESPONSE: 0.05Hz to 60Hz @ -3dB SIGNAL VERIFICATION: LCD Display – ECG Display on LCD MEMORY Recording time: User selectable 24 or 48 Hours Type: Preprogrammed, Burdick non-volatile flash memory Capacity: 128 MB (Removable) PHYSICAL Dimensions: 3.75' x 3.00' x 0.90' Weight with batteries: 4 oz. (112 to 114 grams) Enclosure: Molded plastic / water resistant Operating position: Any orientation, horizontal aspect ELECTRICAL Gain settings: 1X Connector: 20 Pin low profile Patient cable: 7 Pin yoke or 5 Pin yoke, integrated cable, snap-on ENVIRONMENTAL Operating temperature: 0°C (32°F) to 45°C (113°F) Non-operating temperature: -20°C (-4°F) to 65°C (149°F) Operating humidity: 10% to 95% (non-condensing) Non-operating humidity: 5% to 95% (non-condensing) BATTERY Type: (1) AA Alkaline IEC-LR6 Life: 48 Hours |
| EKG/ECG Type | Holter |
| Additional Specifications | CHANNELS: 3 channels RESOLUTIONS: For the 5LR: 16-bit sampling, 4X oversampling RECORDING: Full Disclosure Programmable DOWNLOAD INTERFACE: Removable compact flash (Non-volatile) SAMPLE RATE: 200 samples per second FREQUENCY RESPONSE: 0.05Hz to 60Hz @ -3dB SIGNAL VERIFICATION: LCD Display – ECG Display on LCD MEMORY Recording time: User selectable 24 or 48 Hours Type: Preprogrammed, Burdick non-volatile flash memory Capacity: 128 MB (Removable) PHYSICAL Dimensions: 3.75' x 3.00' x 0.90' Weight with batteries: 4 oz. (112 to 114 grams) Enclosure: Molded plastic / water resistant Operating position: Any orientation, horizontal aspect ELECTRICAL Gain settings: 1X Connector: 20 Pin low profile Patient cable: 7 Pin yoke or 5 Pin yoke, integrated cable, snap-on ENVIRONMENTAL Operating temperature: 0°C (32°F) to 45°C (113°F) Non-operating temperature: -20°C (-4°F) to 65°C (149°F) Operating humidity: 10% to 95% (non-condensing) Non-operating humidity: 5% to 95% (non-condensing) BATTERY Type: (1) AA Alkaline IEC-LR6 Life: 48 Hours |
